Additional information
| Weight | 0,164 kg |
|---|---|
| Reference number | 637210, 1505080, 8143267, A0019976136, 1617187, 99700945116, 42008943, 42009273, 71005255, 2140302017, 110470, 0019976136, 43336140, 6503536, 1111148, 612929, 81521856015, 81521856016, 81521856023, 81521856046, 81521859023, 4630360000, 0019975036, 0019976136, 0029975236, 0039975936, A0019976136, 42008943, 35454707, 1505080, 5000806404, 5000806590, 1934917, 99100360014, 79100360032, 43336140 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | Turn |
| Actuation angle | 90° |
| Calculated Volume (dm³) | 0.1584 |
| Comments | No locking function |
| Exhaust | M16 x 1.5 |
| Max. operating pressure | 145.0 psi |
| Mounting | M28 x 1.5 |
| Nominal diameter | 4.0 mm |
| Port thread 1 | M10 x 1 |
| Port thread 2 | M10 x 1 |
| Port thread 3 | Exhaust |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 3/2 |
| GTIN | 7895851045026 |
| Size (mm x mm x mm) | 64 x 55 x 45 |
| Weight (kg) | 0.164 |
| Weight (lb) | 0.36156 |
| UPC | 193133306542 |
| Brand | WABCO |
