Additional information
| Weight | 0,376 kg |
|---|---|
| Reference number | 5010260246 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuating range | 0.20 in |
| Actuation | Push (M6) |
| Calculated Volume (dm³) | 0.37665 |
| Comments | No locking function (M6) |
| Exhaust | Via hole in body |
| Max. operating pressure | 145.0 psi |
| Mounting | M26 x 1.5 |
| Nominal diameter | 7.0 mm |
| Port thread 1 | M16 x 1.5 |
| Port thread 2 | M16 x 1.5 |
| Port thread 3 | M10 x 1 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 3/2 |
| GTIN | 04057875176633 |
| Size (mm x mm x mm) | 135 x 62 x 45 |
| Weight (kg) | 0.376 |
| Brand | WABCO |
