Twin-Cylinder compressor

Description

Twin-Cylinder compressor, 2-stage

• Brand – WABCO Reman Solutions
• Part type – Remanufactured
• Calculated Volume (dm³) – 33.37
• Cooling – Water
• Crankshaft thread – M20 x 1.5
• Lubrication – Lubrication supplied from engine
• Max. operating pressure – 12.5 bar
• Mounting – Flange mounting
• Operating speed – 3000 (1/min)
• Piston diameter – 85 mm
• Piston stroke – 62 mm
• Port thread 0 – M33 x 2
• Port thread 2 – M22 x 1.5
• Port thread 4 – M14 x 1.5
• Port thread 8.1 -M22 x 1.5
• Port thread 9.1  – M16 x 1.5
• Port thread 9.2 – M16 x 1.5
• Product category – Device
• Swept volume (cm³) – 352 cm³
• Technical specification – OE specification
• Type – Twin Cylinder
• Size (mm x mm x mm) – 370 x 410 x 220
• UPC – 193133412984
• Weight (kg) – 28.69
• Weight (lb) – 63.25

Cross Reference :

• DF – 1696197
• DF – 1674920
• DF – 1681561
• DF – 1687079
• DF – 1622355
• DF – 1624400
