Additional information
| Weight | 9,869 kg |
|---|---|
| Reference number | 1527254, 20721842, 20721842, 3197931, 20410136 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 15.799275 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Output force M | 1933.36 lbf |
| Port thread 11 | M16 x 1.5 JED – 464-0 |
| Port thread 12 | M16 x 1.5 JED – 464-0 |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 76.87 psi |
| Return-spring force | 44.96 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type of operation | Disc |
| GTIN | 04057875283058 |
| Size (mm x mm x mm) | 207x355x215 |
| UPC | 193133354482 |
| Weight (kg) | 9.869 |
| Weight (lb) | 21.76 |
| Type | 24/30 |
| Brand | WABCO |
