Additional information
| Weight | 7,874 kg |
|---|---|
| Reference number | 1506400, 21151105204R, 335984, 4001028, 14316, 1935451, 1020762 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.69 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 14.425 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 480 051 0 |
| Output force M | 1686.07 lbf |
| Port thread 11 | M16 x 1.5 JED – 152 |
| Port threads | M16 x 1.5 |
| Push-rod length | 0.59 in |
| Push-rod thread | Ball R8 |
| Release pressure | 73.97 psi |
| Return-spring force | 49.46 lbf |
| Stroke | 2.52 / 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | 20/24 IBV |
| Type of operation | Disc |
| GTIN | 04057875282587 |
| Size (mm x mm x mm) | 386 x 202 x 185 |
| UPC | 193133354062 |
| Weight (kg) | 7.874 |
| Weight (lb) | 17.359 |
| Total lenght | 10.20 in |
| Brand | WABCO |
