Additional information
| Weight | 0,71 kg |
|---|---|
| Reference number | 1518189, ACHA912, ACHA912 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 1.0074 |
| Charging pressure | 48.59 psi |
| Max. operating pressure | 188.5 psi |
| Opening pressure 21 | 97.18 psi |
| Opening pressure 22 | 97.18 psi |
| Opening pressure 23 | 97.18 psi |
| Opening pressure 24 | 97.18 psi |
| Opening pressure circuit 1+2 | 6.7 + 6.7 bar |
| Port thread 1 | 1/2" – 14 Dry Seal PTF |
| Port thread 21 | 3/8" – 18 Dry Seal NPTF |
| Port thread 22 | 3/8" – 18 Dry Seal PTF |
| Port thread 23 | 3/8" – 18 Dry Seal PTF |
| Port thread 24 | 3/8" – 18 Dryseal PTF |
| Port thread 4 | 3/8" – 18 Dryseal PTF |
| Pressure sensor | No |
| Technical specification | OE specification |
| Type | dynamic |
| GTIN | 04057875290612 |
| Size (mm x mm x mm) | 106 x 108 x 88 |
| Weight (kg) | 0.71 |
| Temperature range | -40°C to +90°C |
| Brand | WABCO |
