Description
- Brand – WABCO Original
- Part type – Premium original quality
- Break point – 0.5 bar
- Calculated Volume (dm³) – 8.95104
- Distance between bolts – 84 x 84 mm
- Exhaust – Snap on contour JED – 463
- Max. operating pressure – 13.0 bar
- Mounting – 4x M8
- Port thread 1 – M22 x 1.5 JED-388
- Port thread 2 – M22 x 1.5 JED – 152
- Port thread 4 – M16 x 1.5 JED – 388
- Product category – Device
- Range of adjustment – 1.0 to 8.6 bar
- Regulating ratio – 1:8
- Technical specification – OE specification
- Temperature range – -40°C to +80°C
- Type – Pneumatic
- Type of operation – Relay Valve
- Size – 320x222x126 (mm x mm x mm)
- UPC – 193133314189
- Weight – 1.92 KG
- Weight – 4.23 LB
Cross reference :
FORD – 9301C442K433BA
