Additional information
| Weight | 3,955 kg |
|---|---|
| Reference number | 95535890104, 7L0 616.007 A, 7L0 616.007 B, 7L0 616.007 C, 7L0 616.007 F, 7L0 616.007 H, 7L0 698 007 D, 7L8 616 006 D, 7L0616007A, 7L0616007B, 7L0616007C, 7L0616007F, 7L0616007H, 7L0698007D, 7L8616006D |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 8.9821 |
| Electrical connection | AMP-Nr. 1-1703532-1/KOSTAL 09441211/AMP-Nr. 1-1703543-0 |
| Important information | Learn more about the core return process (<a href="https://www.wabco-customercentre.com/solutioncentre/s/article/Return-the-core-get-your-money-back?language=en_US" target="_blank">Click here</a> ) |
| Max. operating pressure | 217.56 psi |
| Port thread 0 | 0.45 in |
| Port thread 2 | Ø 0.24 in |
| Protection class | IP 6K7/IP 6K9K |
| Rated current compressor | 35 A |
| Rated current solenoid valve (A) | 0.80 A |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 12 V |
| GTIN | 04057875156802 |
| Size (mm x mm x mm) | 578 x 105 x 148 |
| UPC | 193133422334 |
| Weight (kg) | 3.955 |
| Weight (lb) | 8.7193 |
| Brand | WABCO |
