Aanvullende informatie
| Gewicht | 0,662 kg |
|---|---|
| Reference number | AB9730110000, 445332009, 3454401550, 1505410, 5021172710, 0689331, 1082666, 1444054R, 1506486R, 1519331, 3162118, 317315, 42125234, 689331, MZK4110, 7019169, 4047273, 8285438000, 82855140000, A0034291344, 99707731617, 0319, 001546, 4C462K422AA, A21316000003047B, CF3520600, 200275, 9730110000, 42125234, 5801101681, 1082666, 114519, 3162118, 317315, 3307710R91, 42125234, 5801101681, MZK4110, 1716070091, 2103009, 500945165, 505821202, 945165, 21151102179, 21151103062, 175565, 1133395, 4111190, MZK4110, 502657508, 502957601, 5029846, 502984608, 5029915, 5029915R, 0005662006, 81436066008, 4047273, 81251506011, 81436096005, 81436096008, 81521166008, 81521166010, 81521166013, 81521166014, 81521166016, 81521166019, 81521166020, 81521166021, 81521166022, 81521166023, 81521166035, 81521166036, 81521166037, 81521166043, 81521166047, 81521166049, 9730110000, N1011018624, 24733006, A0034291344, 0024733006, 0004293044, 0004296544, 0014292044, 0014295444, 0014296044, 0014296844, 0014299144, 0024290744, 0024298444, 0024299244, 0024299344, 0024299444, 0034291644, 0034295244, 0034295344, 0034295944, 533531906010, 112231500, 49500721000, 1444054, 1506486R, 0024733005, 24733005, 5010045796, 5021170464, 1313871, 1322986, 2090235, 2090237, 0571174, 0579044, 1378560, 1738439, 1935657, 350000, 350001, 571174, 579044, 050317, 50317, S050318, 22753, 8285438000, 6112KG3527010, DZ93189360033, 533531906010, 79000360311, 79200360048, 89000360397, 99014360047, 99100360074, 55115540, 21151102179, 637206820, 20215552, 215552, 28210200400, 11117866, 3173150, 1082666, 1197892, 1606709, 3162118, 317315, 348909, 42125234, 6886834, 8551104, MZK4110, WA9730110007 |
| Merk | ProVia |
| Type onderdeel | Betrouwbare wisselstukken |
| Technische specificatie | AM Specificatie |
| Productcategorie | Apparaat |
| ProVia Garantie | 1 jaar |
| Berekend volume (dm³) | 2.3438 |
| Demper | – |
| Max. bedrijfsdruk | 10.0 bar |
| Max. tijdelijke druk | 13 bar |
| Openingsdruk | 0.5 bar |
| Ophanging | 4x M8 |
| Poorten | 1, 2: M22 x 1.5; 4: M16 × 1.5 |
| Reactiedruk | 0.20 bar |
| Regelverhouding | 1:1 |
| Schroefdraad poort 1 | M22 x 1.5 |
| Schroefdraad poort 2 | M22 x 1.5 |
| Schroefdraad poort 4 | M16 x 1.5 |
| Temperatuurbereik | -40°C to +80°C |
| Versie | Pressure reduction |
| Werkdruk | 10.0 bar |
| Afmetingen (MM x MM x MM) | 125 x 125 x 150 |
| GTIN | 04057877000202 |
| Gewicht (kg) | 0.662 |
| UPC | 193134001712 |
| Gewicht (lb) | 1.4595 |
| Voorijling | 0.20 bar |
| Merk | WABCO |
