Extra informatie
| Gewicht | 0,684 kg |
|---|---|
| Reference number | 6575332, 5004310018, 1304635, 1505210, 4082200, A0044296544, 355031050A, 3550310-50A, H4356D02001A0, 1417135900001, 1612135900002, 1419335676004, L0356012003A0, 1,41714E+12, 899960117A, S472-195-016-0, ABRA143, 1304635, 6300-4721950160, 81524525019, 81524526019, 4721950160, 4082200, ZG110050007, 0044296544, 5010143058, 81524526038, 0044296544, A0044296544, 5010143058, 81524526038, S4721950160, 81524526019, 1505210, S472-195-016-0, 5010143058, 0044296544, 81524526038, 1934974, WG9000360515/1, WG90003605151, AZ87355000100, WG90003605152, 20252300, WA4721950160, WAB4721950160 |
| Merk | WABCO |
| Type onderdeel | Premium OE kwaliteit |
| Technische specificatie | OE specificatie |
| Productcategorie | Apparaat |
| Afstand tussen gaten | 71×20 mm |
| Berekend volume (dm³) | 0.74423 |
| Beschermingsklasse | IP 67 / IP 69K EN 60529 / IEC 529 |
| Elektrische aansluiting | Bayonet DIN 72 585 A1-3.1-Sn/K1 |
| Max. bedrijfsdruk | 11.0 bar |
| Nominale stroom (A) | 1650 mA |
| Ontluchting | Flap |
| Ophanging | 2x Ø 8.5 mm |
| Opmerkingen | Additionally required 8946011322 |
| Schroefdraad poort 1 | M22 x 1.5 JED-388 |
| Schroefdraad poort 2 | M22 x 1.5 JED – 152 |
| Schroefdraden poort | M22 x 1.5 JED-388 |
| Spanning | 24 V |
| Temperatuurbereik | -40°C to +80°C |
| Afmetingen (MM x MM x MM) | 59 x 106 x 119 |
| Gewicht (kg) | 0.684 |
| UPC | 193133443261 |
| Gewicht (lb) | 1.508 |
| GTIN | 7895851027534 |
| Merk | WABCO |
