Aanvullende informatie
| Gewicht | 1,276 kg |
|---|---|
| Reference number | H03140201, 0830550R, 1506472R, 0830550, 830550, 1506643, 1519298R, 1518257, 0816370, 0925, 006705, TDAS9710021500, CF351054, AJU7602, H03140201, H031402, CF351407, 5311-070-01, 200291, 201993, 9710021500, 9710020000, 500005829, 09988413, 500005829, 101750, 2480005, WZ2480005, 2101004, S971-002-150-0, 58106060, 5810606, 505810606, 79310, 1133358, 4110321, 4110191, 830550, 10170952, 10170852, A05020403, A05020306, 8235-S9710021500, 6300-9710021500, 0005663802, N2523019016, 82580000060, S9710021500, 07110000, 309044, 49500111000, 0830550R, 1506643, 0865625R, 1518257, S971-002-150-0, 5021170445, AG46729002, 5021170441, 5021170440, 5021170439, 1108600, 0001108600, 1738443, 579009, 0579009, 1738441, 2090064, 2090062, 1021172, 050005, 9710021500, 54354, 054354, 9710020000, 4631, 637206780, 3570408, WAB9710021500, WA9710021507, 11018647 |
| Merk | WABCO |
| Type onderdeel | Premium OE kwaliteit |
| Technische specificatie | OE specificatie |
| Productcategorie | Apparaat |
| Afstand tussen gaten | 71 mm |
| Bereik van aanpassing | 0.7 bar |
| Berekend volume (dm³) | 2.309 |
| Max. bedrijfsdruk | 10.0 bar |
| Ophanging | 2x Ø 11.0 mm |
| Schroefdraad poort 1 | M22 x 1.5 JED-152 |
| Schroefdraad poort 12 | M22 x 1.5 JED-152 |
| Schroefdraad poort 2 | 2x M16 x 1.5 JED-152 / 1x Flange M16 x 1.5 JED-152 |
| Schroefdraad poort 3 | Demper |
| Schroefdraad poort 4 | M16 x 1.5 JED-152 |
| Temperatuurbereik | -40°C to +65°C |
| Voertuigtype | Only Emergency valve |
| Voorijling | 0 |
| Afmetingen (MM x MM x MM) | 169 x 112 x 122 |
| GTIN | 04057876223350 |
| UPC | 193133534648 |
| Gewicht (lb) | 2.813 |
| Gewicht (kg) | 1.276 |
| Merk | WABCO |
