Zusätzliche Informationen
| Gewicht | 1,582 kg |
|---|---|
| Reference number | 1505146R, A00143137050080, 81523019031, 001431370580, 0014313705, A00143137050080, 00143137050080, A001431370580, 571101, 1935631, 293139, 79100360085 |
| Marke | WABCO |
| Produkttyp | Premium Originalqualität |
| Technische Spezifikation | OE-Spezifikation |
| Produktkategorie | Gerät |
| Abstand zwischen den Schrauben | 85×85 mm |
| Austauscheinheit für | 973 002 402 0 |
| Berechnetes Volumen (dm³) | 2.4193 |
| Entlueftung | Flap |
| Gewinde Anschluss 11 | M16 x 1.5 |
| Gewinde Anschluss 22 | M16 x 1.5 |
| Gewinde Anschluss 41 | M16 x 1.5 |
| Gewinde Anschluss 42 | M16 x 1.5 |
| Gewinde Anschluss 43 | M16 x 1.5 |
| Lagerung | 4x M8 x 1.25 |
| Max. Betriebsdruck | 8.0 bar |
| Multi-Nennweite (von Anschluss 1 bis x) | 10 mm |
| Temperaturbereich | -40°C to +80°C |
| GTIN | 04057875302926 |
| Gewicht (kg) | 1.582 |
| UPC | 193133375883 |
| Gewicht (lb) | 3.4877 |
| Maße (MM x MM x MM) | 162 x 131 x 114 |
| Marke | WABCO |
